What type of questions are included in this paper?

This paper includes Multiple Choice Questions (MCQ).

How many questions are there in the paper?

There are 100 questions in the paper.

Is this paper available for download?

Yes, this paper is typically available for download as a PDF.

What is the specific paper name or shift?

The specific paper name is Civil Engineering 16th Jan Shift 2.

What is the region associated with this exam?

The region associated with this exam is Rajasthan.

RPSC Lecturer Civil Engineering 2014 Question Paper PDF

Name: RPSC Lecturer Civil Engineering 2014 Question Paper PDF
Creator: RPSC
Keywords: RPSC Lecturer Civil Engineering 2014, Civil Engineering Lecturer Question Paper, RPSC 2014 Exam Paper, Technical Education Lecturer Civil Engineering, Rajasthan PSC Civil Engineering Paper, Lecturer Civil Engineering MCQ, 2014 Civil Engineering Exam, RPSC Previous Year Paper, Civil Engineering Objective Questions, Lecturer Exam Paper PDF

Rajasthan Government Jobs Lecturer 2014

Year 2014
Conducted By RPSC
Questions 100
Maximum Marks 100
Duration 120 minutes Hours
Languages English

Exam Details

Detail	Information
Examination	LECTURER (TECH. EDU.)
Year	2014
Conducting Body	RPSC
Paper	Civil Engineering 16th Jan Shift 2
Subject	Civil Engineering
Duration	120 minutes Hours
Maximum Marks	100
Number of Questions	100
Question Type	Objective (MCQ)

This is the official question paper for the RPSC Lecturer (Technical Education) examination held in 2014, specifically for the Civil Engineering subject. The paper consists of 100 objective-type questions (MCQs) and is allocated a total of 100 marks, with a duration of 120 minutes. This paper is a crucial resource for aspirants preparing for the RPSC Lecturer exam, providing insights into the exam pattern, difficulty level, and important topics covered. Practicing with this paper helps candidates assess their preparation and identify areas for improvement.

Major Topics Covered

Civil Engineering
Poisson's Ratio
Thermal Expansion
Young's Modulus
Mohr's Circle
Stress Analysis
Bending Stress
Shear Modulus
Angle of Twist
Torque

Why This Paper is Important

Useful for LECTURER (TECH. EDU.) preparation
Helps understand the latest exam pattern
Useful for practice and self-assessment
Covers frequently asked General Studies topics
Helpful for analysing question trends

Related Resources

RPSC Lecturer Civil Engineering 2015
RPSC Lecturer Mechanical Engineering 2014
RPSC Lecturer Electrical Engineering 2014
Rajasthan Govt Jobs Previous Papers
RPSC Lecturer Civil Engineering 2014 Answer Key
RPSC Lecturer Civil Engineering Syllabus
Civil Engineering Topics for Competitive Exams
RPSC Lecturer Exam Pattern

Instructions

Question Paper Name: Civil Engineering 16th Jan Shift 2 Subject Name: Civil Engineering Creation Date: 2016-01-15 15:59:41 Duration: 120 Total Marks: 100 Group 1 Group Number: \mathbf{1} 8273477 Group Id: Group Maximum Duration : 0 120 Group Minimum Duration : Revisit allowed for view?: No Revisit allowed for edit?: No Break time: 0 Mandatory Break time: No Group Marks: 100 Civil Engineering Section Id: 8273477 Section Number: \mathbf{1} Online Section type : Mandatory or Optional: Mandatory Number of Questions: 100 Number of Questions to be attempted: 100 Section Marks: 100 Sub-Section Number: \mathbf{1} Sub-Section Id: 8273477 Question Shuffling Allowed: Yes Question Number: 1 Question Id: 827347601 Question Type: MCQ The maximum value of Poisson's ratio for an elastic material is Options: 0.25 0.5 0.75 0.1 Question Number : 2 Question Id : 827347602 Question Type : MCQ A metal bar of length 100 mm is inserted between two rigid supports and its temperature is increased by 10° C.
If the coefficient of thermal expansion is 8 x 10-6 per \rm{^{\circ}C} and the young's modulus is 1.5 x 105 Mpa, the stress in the bar is

Questions (page 2)

Q3. Mohr's circle for the state of stress defined by \beginbmatrix 30 & 0 \ 0 & 30 \endbmatrix Mpa is a circle with

(a) center at (0, 0) and radius 30 Mpa
(b) center at (0, 0) and radius 60 Mpa
(c) center at (30, 0) and radius 30 Mpa
(d) center at (30, 0) and zero radius

Q4. The maximum bending stress induced in a steel wire of modules of elasticity 100 \, kN/m² and diameter 2 mm when wound on a drum of diameter 2 m is approximately equal to

(a) 50 \, N/mm²
(b) 100 \, N/mm²
(c) 200 \, N/mm²
(d) 400 \, N/mm²

Q5. A solid circular shaft of diameter D and length L is fixed at one end and free at the other end. A torque T is applied at the free end. The shear modulus of the material is G. the angle of twist at the free end is

(a) 16 \, TL/π d⁴ \, G
(b) 32 \, TL/π d⁴ \, G
(c) 64 \, TL/π d⁴ \, G
(d) 128 \, TL/π d⁴ \, G

Question paper preview

Scanned pages 1–2 for reference. Download the official PDF for the full paper.

RPSC Lecturer Civil Engineering 2014 question paper page 1 instructions and exam header scan PDF download — Page 1

Free question paper download

Download question paper PDF

6.1 MB
25 pages
PDF format

Frequently asked questions

What is the full name of the exam?

The full name of the exam is LECTURER (TECH. EDU.).

Which year is this question paper from?

This question paper is from the year 2014.

Who is the conducting body for this exam?

The conducting body is RPSC (Rajasthan Public Service Commission).

What subject does this paper cover?

This paper covers Civil Engineering.

What is the total number of marks for the paper?

The total maximum marks for the paper is 100.

What is the duration allowed for the exam?

The duration allowed for the exam is 120 minutes.
